Swing check valves with disc provide reliable backflow prevention and secure operation in industrial systems. Constructed in carbon steel A105 or AISI 316 stainless steel with PTFE disc, they resist pressure and chemical agents, ensuring long-lasting performance. Available with F/F threaded connections from 3/8" to 1" and nominal pressure PN64, these valves deliver durability and high efficiency in hydraulic, chemical, and process applications.
Parameter | Value |
|---|---|
Type | Shut-off valve with plug |
Model | MG100 |
Design | ASME B16.34 |
Available sizes | From 1/4'' to 2'' |
Nominal pressure | From 800 PSI to 6000 PSI |
Available connections | SW (ASME B16.11), NPT or GAS (ASME B1.20.1) |
Available materials | Carbon steel, stainless steel, duplex, superduplex, Incoloy (all bar or forged) |
Internal sealing | Soft seal: Viton, PTFE, Delrin | Metal seal |
Construction features | Face to Face according to Zellinger standard |
Additional features | Compatibility with NACE requirements |
Main parts | 1. Body, 2. Nut, 3. Plug, 4. Spring, 5. Gasket |
Filter by:
| Code | Description | Nominal Diameter (DN) | Nominal Pressure (PN) | Material | Closing | Brand | Seal | Availability | Your Price | Add |
|---|---|---|---|---|---|---|---|---|---|---|
| MAGVRA105MG100012 | Valvola di ritegno A105/INOX/PTFE MG100 F.F. 1/2" | DN15 - 1/2 inch | 64 | A105 | Shutter | Zellinger | MET_MET | Limited quantity | 92,00 € |
|
| MAGVRA105MG100034 | Valvola di ritegno A105/INOX/PTFE MG100 F.F. 3/4" | DN20 - 3/4 inch | 64 | A105 | Shutter | Zellinger | MET_MET | Limited quantity | 96,00 € |
|
| MAGVRA105MG100038 | Valvola di ritegno A105/INOX/PTFE MG100 F.F. 3/8" | DN10 - 3/8 inch | 64 | A105 | Shutter | Zellinger | MET_MET | Not available | 96,00 € |
|
| MAGVRA105MG100100 | Valvola di ritegno A105/INOX/PTFE MG100 F.F. 1" | DN25 - 1 inch | 64 | A105 | Shutter | Zellinger | MET_MET | Limited quantity | 108,00 € |
|
| MAGVRX6MG100012 | Valvola di ritegno INOX316/PTFE MG100 F.F. 1/2" | DN15 - 1/2 inch | 64 | AIS 316 | Shutter | Zellinger | MET_MET | Limited quantity | 127,00 € |
|
| MAGVRX6MG100034 | Valvola di ritegno INOX316/PTFE MG100 F.F. 3/4" | DN20 - 3/4 inch | 64 | AIS 316 | Shutter | Zellinger | MET_MET | Limited quantity | 138,00 € |
|
| MAGVRX6MG100038 | Valvola di ritegno INOX316/PTFE MG100 F.F. 3/8" | DN10 - 3/8 inch | 64 | AIS 316 | Shutter | Zellinger | MET_MET | Limited quantity | 138,00 € |
|
| MAGVRX6MG100100 | Valvola di ritegno INOX316/PTFE MG100 F.F. 1" | DN25 - 1 inch | 64 | AIS 316 | Shutter | Zellinger | MET_MET | Not available | 171,00 € |
|
