316 stainless steel threaded ball valves with lever provide robustness, reliability, and corrosion resistance, making them ideal for hydraulic, industrial, and fluid handling applications. Manufactured in AISI 316 stainless steel, they ensure long-lasting performance even in demanding environments. Available with female threaded connections from 3/8" to 2", they offer tight sealing and smooth operation, suitable for civil, industrial, and professional installations.
Parameter | Value |
|---|---|
Type | Stainless steel 316 ball valve with lever |
Series | SUN WP® |
Body material | AISI 316 (A351 CF8M) |
End piece material | AISI 316 |
Ball material | AISI 316 |
Stem material | AISI 316 |
Seat material | PTFE, PTFE+15% glass, PTFE+carbon graphite, PE-HD |
Seal material | VITON O-ring, upper seal PTFE |
Connections | F/F Rp or M/F R UNI ISO 7/1 (DIN2999) |
Thread | UNI ISO 7/1 (UNI EN 10226) |
Nominal pressure | 100 bar - 40 bar |
Temperature limits | -20°C / +150°C (up to 180°C with CRB) |
Certifications | DVGW gas (PTFE only), TÜV TA Luft (PTFE only) |
Operating lever | Lever (black or yellow) |
Stem seal | Triple stem labyrinth seal with cup springs |
Actuator mounting | ISO 5211 |
General applications | ON/OFF shut-off for gas, water, vacuum, steam, chemicals |
Special executions | NPT ANSI B1.20.1, degreased valves, for oxygen, with balance drilling |
Available diameters | DN 3/8'' ÷ 2'' |
Mounting standard | ISO 5211 |
Filter by:
| Code | Description | Nominal Diameter (DN) | Material | Coupling Connection | Actuation | Brand | Availability | Your Price | Add |
|---|---|---|---|---|---|---|---|---|---|
| EFFEBI2551012 | Valvola a sfera SUN WP Inox 316 FF 1/2" con leva | DN15 - 1/2 inch | 316 stainless steel | Threaded | Lever | Effebi | Not available | 57,00 € |
|
| EFFEBI2551034 | Valvola a sfera SUN WP Inox 316 FF 3/4" con leva | DN20 - 3/4 inch | 316 stainless steel | Threaded | Lever | Effebi | Available | 73,00 € |
|
| EFFEBI2551038 | Valvola a sfera SUN WP Inox 316 FF 3/8" con leva | DN10 - 3/8 inch | 316 stainless steel | Threaded | Lever | Effebi | Available | 51,00 € |
|
| EFFEBI2551100 | Valvola a sfera SUN WP Inox 316 FF 1" con leva | DN25 - 1 inch | 316 stainless steel | Threaded | Lever | Effebi | Available | 77,00 € |
|
| EFFEBI2551112 | Valvola a sfera SUN WP Inox 316 FF 1.1/2" con leva | DN40 - 1 1/2 inches | 316 stainless steel | Threaded | Lever | Effebi | Limited quantity | 135,00 € |
|
| EFFEBI2551114 | Valvola a sfera SUN WP Inox 316 FF 1.1/4" con leva | DN32 - 1 1/4 inch | 316 stainless steel | Threaded | Lever | Effebi | Limited quantity | 103,00 € |
|
| EFFEBI2551200 | Valvola a sfera SUN WP Inox 316 FF 2" con leva | DN50 - 2 inches | 316 stainless steel | Threaded | Lever | Effebi | Limited quantity | 181,00 € |
|
